1200W PSU -BEQUIET! SP - Pure Power 12 (ATX3.0) - Mod PCIE5 (High Gaming)
| Power Rating | 1200W |
| Cooling | 120mm Fan |
| SATA Connectors | 6 |
| Molex Connectors | 2 |
| PCI-E Power | 1 x 16Pin - 4 x 6+2-Pin |
| CE Approved | Yes |
| Voltage Range | 100 - 240V |
General data
| Model | Pure Power 12 M 1200W |
| Continuous power (W) | 1200 |
| Peak power (W) | 1250 |
| Form factor | Version 3.1 |
| Form factor EPS 12V | Version 2.92 |
| Topology | LLC + SR + DC/DC |
| Digitally controlled | - |
| Voltage (Vac) | 110 - 240 |
| Frequency (Hz) | 50 - 60 |
| Input current (A) | 15 / 7.5 |
| Power factor at 100% load | >0.98 |
| Modern standby | ✓ |
| Power consumption in standby (W) | <0.12 |
| Average life time (h / 25°C) | >100,000 |
| Operating temperature up to (°C) | 40 |
Efficiency
| 80 PLUS certification | Gold |
| Efficiency (%) at 230V, 2% load | 72.9 |
| Efficiency (%) at 230V, 10% load | 89 |
| Efficiency (%) at 230V, 20% load | 92.7 |
| Efficiency (%) at 230V, 50% load | 93.7 |
| Efficiency (%) at 230V, 100% load | 91.5 |
Fan and cooling technology
| Cybenetics Noise Rating | - |
| Fan | Silence-optimized be quiet! fan |
| Fan size (mm) | 120 |
| Bearing technology | Rifle |
| Motor technology | 4-pole fan motor |
| Max. fan speed (rpm) | 2700 |
| dB(A) at 10% load | 10.1 |
| dB(A) at 20% load | 10.6 |
| dB(A) at 50% load | 10.7 |
| dB(A) at 100% load | 34.3 |
Output
| Multi-rail operation (12V rails) | 2 |
| 12V single rail operation | - |
| Overclocking key | - |
| +3.3V (A) | 22 |
| +5V (A) | 22 |
| +12V1 (A) | 55 |
| +12V2 (A) | 50 |
| +12V3 (A) | - |
| +12V4 (A) | - |
| +12V5 (A) | - |
| +12V6 (A) | - |
| -12V (A) | 0.3 |
| +5Vsb (A) | 3 |
| Max. combined power 12V (W) | 1200 |
| Max. combined power 12VHPWR (W) | 600 |
| Max. combined power 3.3V + 5V (W) | 120 |
|
